<< | < | AX-RM2S - Two Relay Sequencing Module with Timer
|
| |
|
The AX-RM2S converts a 0-10V dc input signal into a sequenced relay output pair. The module can be configured with or without stage delays and has two possible sequencing modes. Applications include the control of two compressors on a refrigerant circuit. The unit has an adjustable timer function . The AX-RM2S is powered from 24V ac or 24V dc and is designed to fit onto TS35 Section DIN Rail. |
Product Features
| • 0-10V dc Input
• 2 x SPCO Relay Outputs
• On/Off/Auto Override
• Sequencing of two units
| • Adjustable Timer Range
• LED Indication
• High Quality Rising Clamp Terminals
• DIN Rail Mounting (TS35)
|
Input Signal
| 0-10V dc (1mA max)
| Output Contacts
| 2 x SPCO
| Contact Rating
| 12A @ 230V ac (res.)
| Power Supply
| 24V ac or dc
| Power Consumption
| 70mA max@24Vac
|
| 50mA max@24Vdc
| Mode of Operation
| Linear High/ Low Sequencing
|
| Circular Sequencing
| Manual Override
| ON/OFF/AUTO (Link
| Timer
| AX-RM2S
|
| AX-RM2S/2
| Terminals
| Rising Clamp for 0.5-2.5mm2 Cable
| LED Indicators
| On when relay energised
| Ambient Temp. Range
| 0 to 50’C
| Dimensions
| 83mm (l) x 46mm (w) x 45mm (h) (approx.)
| Weight
| 72 gms
| Country of Origin
| United Kingdom
|
| AX-RM2S.pdf / Two Relay Sequencing Module with Timer |  |
|
|
|
